- Weight
- 490 kg
- Dimensions
- 194.4 × 137.6 × 242.5 cm
- Colour
- Matte black
- Nominal operating power
- 7 000 W (7.00 kW)
- Cool-down power
- 9 000 W (9.00 kW)
- Calculated energy
- 7.00 kWh at 7.00 kW over one hour
- EU power supply
- 400 V three-phase, 50 Hz. Two connections, one per cooling unit. Max. 10 A operating current and 16 A protection per connection.
- Cooling level
- Down to −120 °C
- Evaporator temperature
- Down to −110 °C
- Cooling
- Water-cooled, integrated cooling unit
- Cooling water
- Nominal flow 38 l/min. Inlet max. 6 °C, outlet 10 °C.
- Water connection
- G 3/4 inch male thread, inlet and outlet. Fresh water with 25% glycol.
- Cooling capacity
- 12.60 kW thermal capacity; distinct from electrical power
- Heat rejection to room
- 3.00 kW
- Room conditions
- 15–23 °C, max. 35% relative humidity. Minimum room volume 25 m³.
- Noise at 3 m
- ≤60 dB(A)
- Clearance
- Clear servicing access at the cooling-unit side and room for door opening. Positioning is planned before installation.
